Dry-type transformer efficiency affects energy use, operating temperature, cooling requirements, and long-term ownership cost. However, efficiency cannot be judged from one percentage alone.
Buyers should compare no-load loss, load loss, operating load, power factor, harmonics, cooling method, ambient conditions, and test conditions. A transformer with low losses at one operating point may not provide the same advantage under a different load profile.
The correct comparison starts with the project’s actual operating pattern and the supplier’s complete technical data.
Dry-type transformer efficiency depends on both no-load loss and load loss.
No-load loss occurs whenever the transformer is energized, even when the load is low.
Load loss changes with current and can become important during high-demand operation.
Harmonics, ambient temperature, cooling fans, and power factor affect real operating performance.
Efficiency values should be compared under the same voltage, frequency, load, and test conditions.
Life-cycle cost may be more useful than purchase price when the transformer operates for many hours.
The final comparison should use verified technical data rather than general efficiency claims.
Transformer losses are commonly divided into no-load loss and load loss. Both should be included when comparing dry-type transformers.
No-load loss is the power consumed by the transformer when it is energized but supplying little or no external load.
It is mainly associated with the magnetic core and remains present during normal energized operation. The actual value depends on:
Core material
Core construction
Magnetic flux density
Voltage
Frequency
Manufacturing quality
Transformer rating
A transformer connected continuously to the electrical system will produce no-load loss even during periods of low demand.
This makes no-load loss important for:
Standby transformers
Lightly loaded distribution systems
Facilities that operate around the clock
Data centers
Commercial buildings
Backup power systems
Seasonal facilities
Load loss is related to current flowing through the transformer windings and other conductive parts.
It is influenced by:
Winding resistance
Conductor size
Current level
Temperature
Stray losses
Harmonic current
Connection design
Load loss generally increases as the transformer carries more current. It can become a major part of total loss during peak operation.
Transformer efficiency changes with load. A transformer may show a strong efficiency value at a rated load, but the facility may operate at a much lower or more variable load for most of the year.
The comparison should include:
Normal operating load
Peak operating load
Minimum load
Seasonal load
Standby periods
Expected future load
Power factor
Operating hours
A rated-load efficiency value may not represent the yearly energy performance of the installation.
For example, a transformer operating continuously at a moderate load may have a different annual loss profile from a transformer that operates near full load for short periods.
Ask the supplier for loss data at relevant operating points, such as:
Low load
Typical load
High load
Rated load
Short-time overload where applicable
The project team can then compare the transformer with the expected load curve.
The most suitable transformer is not always the one with the lowest value for only one loss category.
A design with very low no-load loss may have different winding or material choices that affect load loss, physical size, cost, or thermal behavior. A design optimized for heavy loading may require a different balance.
The buyer should compare:
No-load loss
Load loss
Total loss at normal load
Total loss at peak load
Temperature rise
Transformer dimensions
Purchase price
Cooling requirements
Expected operating hours
For a facility with stable high loading, load loss may have a strong influence on annual energy use.
For a lightly loaded or continuously energized transformer, no-load loss may be more important.
For a facility with large daily fluctuations, both values should be included in a load-based assessment.
Transformer efficiency can be expressed as:
Efficiency = output power ÷ input power × 100%
The difference between input and output power represents the transformer’s losses.
When using this relationship, also consider:
Power factor
Load level
Voltage
Frequency
Harmonic content
Temperature
Measurement conditions
A transformer may transfer the same apparent power at different power factors, but the real output power and operating losses may differ.
Power factor affects the relationship between kW and kVA. It also affects the current required for a given real power output.
Lower power factor may increase current and influence winding losses. The supplier should receive realistic power-factor information when preparing the technical offer.
Efficiency and loss data are useful only when the test conditions are clear.
Ask the supplier to identify:
Test voltage
Test frequency
Load level
Winding temperature
Ambient temperature
Measurement method
Tolerance
Rated capacity
Cooling condition
Harmonic condition
Applicable test documents
Do not compare one supplier’s loss value with another supplier’s value if the transformer ratings or test conditions are different.
When reviewing proposals, check whether each transformer has the same:
Capacity
Voltage ratio
Frequency
Phase arrangement
Impedance
Cooling method
Enclosure
Tap arrangement
Insulation design
Temperature-rise requirement
A lower loss figure may be connected to a different configuration. The project team should compare equivalent designs before making a decision.
Non-linear loads can create additional heating and losses in transformer windings, conductors, and magnetic components.
Examples include:
Variable-frequency drives
UPS systems
Rectifiers
Battery chargers
LED lighting
Switching power supplies
Industrial automation equipment
Data-processing equipment
Harmonic currents may cause the real operating losses to differ from a simple sinusoidal-load calculation.
Provide the supplier with:
Harmonic current information
Load composition
Neutral loading
Existing filters
UPS information
Generator operation
Power-quality requirements
If the harmonic profile is unknown, the technical offer should identify the need for additional engineering review.
Transformer losses become heat. That heat must be removed from the electrical room.
The comparison should include:
Transformer heat output
Natural-air cooling
Forced-air cooling
Fan power
Ventilation requirements
Room temperature
Cooling-system operation
Fan maintenance
Alarm and failure conditions
A transformer with forced-air cooling may have additional fan energy consumption. The fan’s operating hours and control method should be considered when estimating total energy use.
The transformer may be part of a larger electrical-room cooling load. Higher losses can increase the demand on air-conditioning or ventilation equipment.
The project team should evaluate:
Electrical loss
Cooling energy
Room temperature
Available airflow
Fan operation
Maintenance requirements
Impact on nearby equipment
This gives a more complete picture of operating cost.
A lower initial purchase price does not always mean lower total cost.
The economic comparison may include:
Purchase price
Installation cost
No-load energy cost
Load-loss energy cost
Cooling energy
Maintenance
Downtime risk
Replacement cost
Expected operating period
A simple annual loss estimate can be based on:
Annual energy loss = average loss × operating hours
The actual calculation should use the facility’s load profile instead of assuming that the transformer operates at full load all year.
A life-cycle comparison should include realistic assumptions for:
Electricity price
Operating hours
Load variation
Energy escalation
Maintenance
Expected service period
Expansion
Replacement planning
Do not create a financial conclusion from a single efficiency percentage. The result depends on how the transformer operates in the real system.
Efficiency and loss data may be affected by the installation environment.
Review:
Ambient temperature
Installation altitude
Ventilation
Humidity
Dust
Enclosure
Indoor or outdoor use
Harmonic load
Continuous loading
Cooling arrangement
A transformer operating in a hot or poorly ventilated room may experience different thermal conditions from a transformer in a clean, cool electrical room.
SNTOOM’s dry-type transformer range can be reviewed when comparing construction, cooling, efficiency targets, impedance, and environmental requirements for a project.
A technical offer should include enough information for a meaningful comparison.
Request:
Rated capacity
Primary and secondary voltage
Frequency
No-load loss
Load loss
Total loss at stated load
Efficiency at relevant operating points
Power factor assumptions
Temperature-rise information
Cooling method
Harmonic assumptions
Impedance
Noise information
Test documents
Tolerances
The supplier should identify which values are guaranteed, which are typical, and which still require engineering approval.
Useful questions include:
At what load was efficiency measured?
What temperature was used?
Were harmonics included?
Was forced-air cooling operating?
Were the values measured or calculated?
What tolerance applies?
Is a routine test report available?
Are the values for the complete unit or a reference design?
These questions help prevent misunderstandings during procurement.
Efficiency should not be evaluated separately from other technical requirements.
Also review:
Voltage ratio
Phase arrangement
Impedance
Insulation level
Partial-discharge requirements
Short-circuit withstand
Noise
Enclosure
Cooling
Monitoring
Maintenance access
Delivery documents
A transformer with an attractive loss value may not be suitable if it does not match the system voltage, installation environment, protection design, or available space.
For unusual voltage, environmental, or performance requirements, discuss special transformer solutions before finalizing the purchase specification.
Before selecting a supplier, organize the proposals using the same categories.
Record:
Product type
Capacity
Voltage ratio
Frequency
No-load loss
Load loss
Efficiency test point
Temperature-rise class
Cooling method
Impedance
Noise
Dimensions
Weight
Price
Warranty
Test documents
Delivery scope
The comparison should also include the assumptions behind each value.
If the proposals use different test points or different operating conditions, request clarification before ranking them.
Avoid these common mistakes:
Comparing efficiency percentages without checking load conditions
Ignoring no-load loss
Ignoring load loss at the actual operating current
Using rated-load efficiency as annual efficiency
Forgetting power factor
Ignoring harmonics
Excluding fan power from the energy comparison
Comparing transformers with different capacities
Ignoring ambient temperature
Treating typical values as guaranteed values
Choosing the lowest purchase price only
Failing to request test conditions
Assuming low loss means every other specification is suitable
Comparing dry-type transformer efficiency requires more than selecting the highest percentage in a quotation.
The project team should review no-load loss, load loss, operating load, power factor, harmonics, cooling, ambient conditions, test methods, and life-cycle cost. The comparison should be based on equivalent transformer configurations and realistic operating assumptions.
A complete technical offer helps buyers understand how the transformer will perform in the actual electrical system. It also makes it easier to compare purchase price, energy use, cooling requirements, and long-term maintenance.
Need help comparing dry-type transformer losses and efficiency?
Send your capacity, voltage, load profile, operating hours, power factor, harmonic information, cooling conditions, and required test documents through the SNTOOM contact form. Our team can discuss a suitable transformer configuration and technical comparison basis.
Dry-type transformer efficiency is the ratio of output power to input power after accounting for transformer losses. It varies with load, power factor, temperature, frequency, harmonics, and cooling conditions.
No-load loss is the power consumed by an energized transformer when it supplies little or no external load. It is mainly associated with the transformer core.
Load loss is related to current flowing through the transformer windings and other conductive components. It generally increases as the operating current increases.
The answer depends on the operating profile. No-load loss may be important for continuously energized, lightly loaded transformers. Load loss may be more important for transformers that operate near high load for long periods.
Harmonic currents can increase heating and additional losses in the transformer and connected conductors. Harmonic information should be provided for systems with UPS, drives, rectifiers, or electronic power supplies.
Yes. If forced-air cooling is used, fan energy and operating hours should be considered when estimating total operating cost.
Compare values only when the transformer capacity, voltage, frequency, load point, temperature, cooling method, and test conditions are equivalent.
