Transformers are essential for the transmission and distribution of electrical power. Among the various types, dry type transformers are known for their distinct characteristics and operational requirements. This article delves into the concept of temperature rise in dry type transformers, with a focus on the products offered by Zhejiang Shuntong Electric Co., Ltd.
Transformer temperature rise refers to the increase in temperature of the transformer’s core and windings during operation. It is a natural occurrence due to the electrical and magnetic losses within the transformer. Temperature rise is a critical factor as it affects the transformer’s lifespan, efficiency, and reliability.
Dry type transformers, unlike oil-immersed transformers, do not use oil for cooling. Instead, they rely on air for cooling, which makes temperature management crucial. The temperature rise in dry type transformers is primarily due to:
Load Current: The current flowing through the windings generates heat.
Core Losses: Hysteresis and eddy current losses in the core material contribute to heat generation.
Temperature rise ratings are specified by standards such as IEEE and IEC. These ratings define the maximum allowable temperature increase above the ambient temperature. For dry type transformers, common temperature rise ratings include:
Class A: 55°C rise over ambient.
Class B: 65°C rise over ambient.
Class F: 80°C rise over ambient.
Class H: 100°C rise over ambient.
The choice of rating depends on the application and the expected load conditions.
The temperature rise rating has several implications for dry type transformers:
Reliability: A lower temperature rise rating generally indicates a longer transformer life and higher reliability.
Efficiency: Lower temperature rises can lead to better efficiency as less energy is lost as heat.
Material Selection: The choice of insulation and other materials depends on the temperature rise rating to ensure they can withstand the operating temperatures.
Design: Transformers with different temperature rise ratings may require different cooling systems and physical designs.
Zhejiang Shuntong Electric Co., Ltd. specializes in oil-immersed transformers, but the principles of temperature rise apply to their dry type counterparts as well. Their transformers are designed to withstand thermal shock, overload capacity, and operate in high-flame retardant and fire-resistant environments. These features are essential for maintaining stable temperatures during operation.
In environments like airports, power plants, and hospitals, where reliability is paramount, managing temperature rise is crucial. Shuntong’s transformers are designed to operate efficiently and safely, even in challenging conditions.
Understanding the temperature rise in dry type transformers is vital for ensuring their optimal performance and longevity. By adhering to the appropriate temperature rise ratings and design standards, manufacturers like Zhejiang Shuntong Electric Co., Ltd. can deliver reliable and efficient transformers suitable for a wide range of applications.
