I. Product Overview
The TSD wall-mounted servo AC stabilizer is an advanced power equipment specifically designed to address voltage fluctuation issues. With its wall-mounted design, it offers convenient installation and space-saving benefits, suitable for use in various environments. The product boasts high stability, precision, and efficiency, effectively safeguarding the stable operation of the power system and extending equipment lifespan.
II. Product Features
Efficient and Stable: The TSD stabilizer employs advanced servo control technology to continuously monitor grid voltage fluctuations and quickly adjust to ensure stable output voltage, minimizing equipment damage caused by voltage instability.
Accurate Control: The product exhibits high-precision voltage regulation capabilities, allowing precise adjustment of output voltage based on actual needs to meet the power requirements of different devices.
Energy-Saving and Environmentally Friendly: While maintaining voltage stability, the TSD stabilizer also focuses on energy conservation and emission reduction. Its efficient operation helps reduce energy consumption and minimize environmental impact.
Safe and Reliable: Manufactured with high-quality materials, the product boasts excellent insulation performance and short-circuit resistance, ensuring safe and reliable operation during use.
III. Application Fields
The TSD wall-mounted servo AC stabilizer is widely used in computer rooms, medical equipment, precision instruments, communication devices, and other fields, providing stable power guarantees for various critical devices. Additionally, it is suitable for household and office settings, ensuring the safety and stability of daily electricity usage.
Input Voltage | Single-phase 160V~250V(140V~250V) | Delay Time | 5s±2s， 5min±2min |
Output voltage | Single-phase 220V/110V | Ambient Temperature | -5℃ ~ +40℃ |
Stabilization accuracy | 220V±3%，110V±3% | Relative Humidity | ≥90% |
Working Frequency | 50/60Hz | Adjust Time | ＞90% |
Adjust Time | ＜1s(When the input voltage changes 10%) | Load Power Factor | 0.8 |
Wave Distortion | No additional waveform distortion | Electric Strength | 1500V/min |
Over-voltage protection | 246V±4V | Insulation Resistance | ≥2MΩ |
Under-voltage protection | 184V±4V |
Model（KVA） | Product Size L×W×H（cm） | Packing L×W×H（cm） | Weight（KG） | Package (Set/carton） |
TSD-3 | 37×25×13 | 42×32×18 | 9 | 1 |
TSD-4 | 37×25×13 | 42×32×18 | 12 | 1 |
TSD-5 | 43×30×14 | 49×36×19 | 16 | 1 |
TSD-6 | 43×30×14 | 49×36×19 | 26 | 1 |
TSD-7 | 43×30×14 | 49×36×19 | 27 | 1 |
TSD-8 | 48×32×19 | 52×38×25 | 18 | 1 |
TSD-10 | 48×32×19 | 52×38×25 | 22 | 1 |
Key Features:
Multi-Phase Compatibility: Offering both three-phase and single-phase capabilities, this voltage regulator is highly adaptable to various electrical configurations. It seamlessly integrates into both 220V and 380V systems, ensuring compatibility with a broad spectrum of applications.
Precision Voltage Control: Equipped with advanced electronics and control mechanisms, the voltage regulator precisely adjusts and maintains output voltage within tight tolerances. This ensures that connected equipment operates at peak performance, reducing wear and tear and extending equipment lifespan.
Protection Against Voltage Fluctuations: Voltage surges and sags can damage sensitive electronic equipment. Our voltage regulator effectively mitigates these fluctuations, providing a stable and consistent power supply to protect your valuable assets.
Dynamic Response: The voltage regulator features a rapid response time, enabling it to adjust to changing voltage conditions almost instantaneously. This ensures continuous and uninterrupted power delivery, even during periods of high demand or sudden load changes.
Easy Installation & Operation: Designed for user-friendliness, the voltage regulator is straightforward to install and configure. It comes with clear instructions and can be easily integrated into existing electrical systems.
Durability & Reliability: Constructed from high-quality materials and components, the voltage regulator is built to withstand the rigors of daily use. Its rugged design ensures long-term durability and reliable performance, even in challenging environments.
Safety Features: Equipped with built-in safety features such as overcurrent protection, overheating prevention, and short-circuit protection, the voltage regulator ensures safe operation at all times.
Versatile Applications: Ideal for a wide range of applications, including power plants, factories, offices, data centers, and homes, this voltage regulator ensures stable voltage supply for all types of electrical equipment.
Technical Specifications:
Voltage Range: 220V/380V (adjustable)
Phase: Three-phase or Single-phase selectable
Accuracy: ±X% (specific accuracy rating as per model)
Frequency: 50/60 Hz
Load Capacity: [Specified kW/kVA rating]
Response Time: [Specified milliseconds]
Protection Features: Overcurrent, overheating, short-circuit protection
Dimensions: [L x W x H in mm/inches]
Weight: [Approximate weight in kg/pounds]
Customization Options:
We offer customization options to suit your specific requirements, including customized voltage ranges, additional safety features, and special enclosures designed to withstand harsh environments.
Conclusion:
Our Three/Single-Phase 220V/380V Electric Voltage Regulator is the ultimate solution for maintaining stable and reliable voltage levels in your electrical systems. With its precision control, robust construction, and versatile application capabilities, it ensures optimal performance of your equipment and protects against voltage-related damages. Contact us today to learn more about how our voltage regulators can enhance the reliability and efficiency of your electrical systems.
