Product description
FSVR line automatic voltage regulator is a device that tracks the line voltage change and automatically adjusts the transformation ratio of the device to ensure the stable output voltage. The input voltage can be automatically adjusted in the range of -20% to +10%. It is especially suitable for lines with large voltage fluctuations or lines with large voltage drops. This feeder voltage regulator is installed in series at 6kV, 10kV, In the middle and rear part of the 35kV line, the line voltage is adjusted within a certain range to ensure the user's power supply voltage and reduce the line loss of the line. In addition, the FSVR feeder automatic voltage regulator is also suitable for substations where the main transformer does not have the ability to adjust voltage. Install this type of voltage regulator on the outlet side of the substation transformer to ensure the bus voltage on the outlet side. It is widely used in the national rural power grid, urban power grid, oil field, coal, chemical industry, substation and other fields.
Feature
The whole device has large capacity, low loss, small size, and easy installation and maintenance;
Automatically adjust the three-phase on-load tap switch gear position by tracking the voltage change, with reliable action and high voltage adjustment accuracy;
The voltage reference, action delay, allowable range, limit of times can be adjusted according to needs, and the parameter setting is flexible and convenient;
Display the number of FSVR on-load tap-changer gear actions and the current gear position, with the highest and lowest gear indications;
With the upper limit and lower limit protection of the gear position, the action time limit function, which effectively improves the reliability of the product;
The controller has over-voltage rapid drop and under-voltage protection functions. When the line is in an over-voltage or under-voltage state, the controller automatically locks; to ensure the safe operation of the on-load tap changer
The controller adopts industrial-grade control chip, which has high reliability and strong anti-interference ability, which can adapt to the harsh outdoor environment;
With RS485 communication interface, the parameters of the controller can be viewed and modified within 30m from the installation point through the wireless communication module.
Cloud remote control can be added.
Product Standards
1. Production design standards
JB8749-1998 General technical requirements for voltage regulators
GB1094-2013 Power Transformer
GB/T6451-2008 Three-phase oil-immersed power transformer technical parameters and requirements
GB/T17468—1998 Guidelines for Selection of Power Transformers
GB10230—2007 On-load tap changer
GB/T1058-1989 Application guidelines for on-load tap-changers
DL/T572-2010 Power Transformer Operation Regulations
2. Basic standards for use
FFSVR line automatic voltage regulator installation point voltage meets the national standard GB/T12325-2008 power supply voltage deviation standard: the absolute value of the positive and negative deviations of the power supply voltage of 35kV and above does not exceed 10% of the rated voltage; 20kV and below three The allowable deviation of phase power supply voltage is ±7% of the rated voltage; the allowable deviation of 220V single-phase power supply voltage is +7%, -10% of the rated voltage.
Technical parameters
1. Environmental conditions
1.1 Altitude: ≤2000m
1.2 Ambient temperature: -25℃～+45℃
1.3 Relative humidity: less than 90%
1.4 Anti-pollution ability: Level III
1.5 Installation tilt: <2%
1.6 There is no dirty or corrosive medium around the device that seriously affects the insulation performance of the device, and there is no risk of fire and explosion in the workplace, and no severe vibration.
Note: When the working environment exceeds the above conditions, the user needs special instructions when ordering.
2. Technical parameters
2.1 Rated capacity: 630KVA, 800KVA, 1000KVA, 1250KVA, 1600KVA, 2000KVA, 3150KVA, 4000KVA, 5000KVA 6300kVA, 8000KVA 10000kVA, etc. Special specifications can be customized.
2.2 Rated voltage: 0.4KV, 6kV, 10kV, 35kV
2.3 Frequency rate: 50 Hz
2.4 Voltage adjustment range: -20%~+20%
2.5 gears: 7-9 gears
2.6 Connection group: Ya0
2.7. Transformer oil grade: 25#, 45#
2.8 Cooling method: ONAN
2.9 Insulation level: LI60kV/AC25kV(6kV), LI75kV/AC35kV(10kV), LI200kV/AC85kV(35kV)
2.10 The FFSVR line automatic pressure regulator adopts a fully sealed corrugated oil tank with oil temperature indication and pressure release valve; the tank has a built-in signal power supply and sampling PT to provide sampling signals and working power for the controller;
3. The basic parameters of the regulator switch:
3.1 The resistance of each switch contact: it is related to the number of on-load tap changers, <500μΩ
3.2 Switch electric operation time for one time: 10s
3.3 Switching time of switch transition resistance: 15～24ms
3.4 The electrical life of the contacts of the switch under the rated capacity:> 50000 times
3.5 Switch mechanical life: 〉500000 times
3.6 Switching transition mode: single resistance or double resistance
4. Performance parameters of the regulator:
4.1 Power supply: AC/DC 110-450V
4.2 Rated frequency: 50Hz
4.3 Maximum power consumption: 25W
4.4 Analog input: 2 voltages (0-250V)
4.5 Switch input: 10 way empty contact inputs
4.6 Switch output: 2 way(AC250V/380V l6A)
4.7 Measurement accuracy: Voltage (0.5%)
4.8 Anti-interference level: meet the requirements of IEC61000-4: 1995 level
Core Features & Benefits:
Online Feed Regulation: The SVR Series operates seamlessly in real-time, continuously monitoring and adjusting the output voltage to maintain a precise and stable level. This online feed capability ensures that even during sudden fluctuations in input voltage, the output remains constant, safeguarding your equipment from potential damage.
Precision Voltage Regulation: Equipped with advanced control algorithms, the transformer achieves exceptional voltage regulation accuracy, typically within ±1% or better. This precision is crucial for maintaining the performance and longevity of sensitive electronic devices, such as computers, servers, medical equipment, and precision machinery.
Broad Voltage Range Compatibility: T
he SVR Series is designed to handle a wide range of input voltage variations, making it suitable for various grid conditions and locations. This flexibility ensures reliable operation in diverse environments, from stable urban grids to remote or unstable rural ar
eas.
Efficient Energy Management: The transformer utilizes high-efficiency components and intelligent control strategies to minimize power losses and optimize energy usage. This contributes to cost savings, reduced heat generation, and a smaller carbon footprint.
Protection Against Surges & Transients: Integrated surge protection and transient suppression capabilities shield your equipment from harmful voltage spikes and dips, providing an extra layer of protection against power disturbances.
Easy Installation & Maintenance: The SVR Series transformer is designed for straightforward installation and maintenance. It comes with clear installation instructions, user-friendly control interfaces, and remote monitoring capabilities (optional), simplifying setup, operation, and troubleshooting.
Reliable & Durable Construction: Built with high-quality materials and robust construction, the transformer is designed for long-term reliability and durability. It can withstand harsh industrial environments and maintain consistent performance over time.
Applications:
Sensitive electronic equipment and data centers
Medical facilities and laboratories
Manufacturing and industrial automation
Telecommunications and networking infrastructure
Research and development centers
Anywhere a stable and reliable power supply is crucial
Conclusion:
The SVR Series Online Feed Automatic Voltage Regulating and Stabilizing Transformer is the ideal solution for maintaining a stable and high-quality power supply in critical applications. Its advanced voltage regulation capabilities, broad compatibility, and efficient energy management make it a valuable asset for any organization that relies on sensitive electronic equipment or processes. Contact us today to learn more about how the SVR Series can enhance the reliability and performance of your power supply system.
